Installation Notes and Restrictions 2-33
Installing the Power Supply
If a power supply is not installed in the base of the P1535 terminal, install a 19 V power
supply.
Caution: The P1535 terminal requires the NCR 19 V or 24 V power supply that is
shipped with the terminal. Use of other power supply may cause damage to the unit. Do
not connect or disconnect the 19 V or 24 V Power Cable from the terminal with the
ACPower Cord still connected to an ACoutlet.
To install the 19V power supply, perform the following procedure:
1. Unpack the terminal in the desired location.
2. Pivot the display toward the back.
3. Remove the Upper Stand Cover by pivoting it away from the stand. The cover has a
simple snap fit connection at the top.
