CONNECTING OTHER MACHINES LIKE VIDEO
NAMES AND FUNCTIONS OF CONNECTIVE TERMINALS
R-AUDIO-L VIDEO
R-AUDIO-L
Cr-DVD-Cb
VIDEO(DVD-Y)
(1)
AUDIO SET
GAME PLAYER
VCR
CAMCORDER
LASER DISC PLAYER
DVD
Input terminals of VIDEO1
(picture, sound on left, right)
DVD Input terminals
VIDEO 2 Input/Output terminal
(Scart Jack Input/Output)
This always provides with TV
signal output of the selected
channel.
