CONNECTING WITH AUDIO SET
MWhen listening to sound in powerful AUDIO, while watching the picture on TV.
MConnect external input terminal of AUDIO to right & left sound output of TV signal.
R-AUDIO-L VIDEO
R-AUDIO-L
Cr-DVD-Cb
VIDEO(DVD-Y)
RIGHT LEFT
M When connecting other equipment, please ensure you turn the main switch OFF to prevent any
damage to the equipment.
