NEC FS-8002 - Page 7

6
R-AUDIO-L VIDEO
R-AUDIO-L
Cr-DVD-Cb
VIDEO(DVD-Y)
(1)(1)
BACK
This always provides with TV
Video 1 input terminals
ANT
TOP
VIDEO 2(SCART JACK) input
/
output terminal
(SCART does not supports S-VIDEO)
(2)
signal output of the selected channel.
A/V OUT OF SCART TERMINAL
will provide with TV signal output of the selected channel.
