8
(12)
Answer Key (with light) When LED on this key is lit, press this key to answer the incoming call.
(13)
Recall Key To finish a call and hear the dial tone to make an another call.
(14)
Programmable Keys
(with light)
These keys can be programmed as Flexible line key/Programmable feature
key by system administrator.
(15)
Home Key To go back to the Home window.
(16)
Soft keys
The feature name is shown at the bottom of the LCD. The appropriate
feature key is displayed on the screen according to the call handling process.
(17)
LCD To display date or dialed number, etc.
(18)
Call Indicator Lamp
The lamp at the top corner of display flashes when a call terminates to the
terminal and when you use voice mail.
the lamp lights when a message has been left.
(19)
Touch Button Area
The touch screen button area on the telephone. This area includes three
buttons; the Back Key (2), the Home Key (16) and the Multi Key (20).
(20)
Multi Key To display the application switch screen.
No. Name Function
