89
9. Maintenance
5. Put the filter unit back to the projector cabinet.
Insert two catches of the tip of the filter unit into the groove of
the cabinet, and push the button to close the filter unit.
Push the filter unit until it clicks into place.
This completes the filter replacement.
Go on to the clearing lamp and filter hour meters.
To clear the lamp usage hours and the filter usage hours:
1. Place the projector where you use it.
2. Plug the power cord into the wall outlet, and then turn on the projector.
3. Clear the lamp usage hours and the filter usage hours.
1) Press MENU button and the OSD displays. Press button to select Expand menu, press button or ENTER.
2) Press button to select "Lamp counter reset", press button or ENTER. The “Lamp counter reset?” mes-
sage displays. Select Yes to proceed.
Press button to select "Filter", press button or ENTER. Press button to select “Filter counter reset”
and press ENTER. The “Filter counter reset”?” message displays. Select Yes to proceed.
Select
ENTER
Back
EXIT
Move
Filter counter reset?
Yes No
Select
ENTER
Back
EXIT
Move
Lamp counter reset?
Yes No

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NEC MC453X and is the answer not in the manual?

NEC MC453X Specifications

General IconGeneral
Native aspect ratio4:3
Projection distance0.9 - 10.9 m
Vertical scan range50 - 120 Hz
Horizontal scan range15 - 100 kHz
Projection technologyLCD
Contrast ratio (typical)16000:1
Screen size compatibility30 - 300 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal-30 - 30 °
RMS rated power16 W
Number of built-in speakers1
PlacementCeiling, Floor
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Lamp power240 W
Lamps quantity1 lamp(s)
Light source typeLamp
Lamp power (economic mode)150 W
Service life of light source10000 h
Service life of light source (economic mode)20000 h
Built-in display-
FocusManual
Throw ratio1.5 - 1.8:1
Focal length range19.158 - 23.018 mm
Aperture range (F-F)1.6 - 1.76
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)320 W
Power consumption (standby)0.5 W
Power consumption (typical)305 W
Power consumption (economy mode)215 W
Power consumption (network standby)2 W
Noise level37 dB
CertificationUL, FCC Part15 Class B, CAN/CSA, ICES-003 Issue 6
Noise level (economic mode)29 dB
Full HDNo
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format systemNot supported
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100 Mbit/s
Storage temperature (T-T)-10 - 50 °C
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)20 - 80 %
Remote control typeIR
Weight and Dimensions IconWeight and Dimensions
Depth261 mm
Width345 mm
Height108.4 mm
Weight3300 g
Package depth390 mm
Package width450 mm
Package height200 mm
Package weight4700 g
