2. Projecting an Image (Basic Operation)

❻ Correcting Keystone Distortion [KEYSTONE]

You may adjust keystone distortion of image in your projector with the V keystone adjustment. Follow steps below

to adjust keystone distortion of projected image manually.

Press the KEYSTONE button on your remote controller. The keystone adjustment dialog box displays ( including

H/V keystone, 4-Corner correction, 6-Corner correction, Curved correction, Grid Image Tune, Reset) , press ▲▼◀

▶button to adjust keystone distortion.

You may save your settings for keystone adjustment.

• H/V Keystone......Adjust the projected image when the projector is on the horizontal or vertical keystone distortion.

• 4-Corner correction......Adjust the projected image when the projector is keystone distortion of four corners .

• 6-Corner correction......Adjust the projected image when the projector is keystone distortion of four corners.

• Curved correction......Adjust the projected image when the projector linearity is uneven or the projected images

bent vertically and horizontally.

• Grid Image Tune......Adjust the local points of the projected image.

• Reset......The correction values will be restored to the factory defaults.

NOTE:

• The arrow mark looks white when there is no keystone adjustment in existence.

• The arrow mark indicating the adjustment direction turns red.

• The arrow mark disappears when the maximum adjustment limit reaches.

• The keystone prompt box will disappear if you press the keystone button again when it is displaying. Press the ENTER button again to

switch the four correction items.

• The adjustable range is subject to source of signal input.

• For further details about Keystone function, please turn to page 44-48.

• When using the VIEWER, you cannot use ▼ button on the panel to directly call up the keystone correction menu.

H/V Keystone

4-Corner correction

6-Corner correction

Curved correction

Grid Image Tune

Reset value

• Only for ME403U

H/V Keystone

4-Corner correction

Reset value

• Only for ME423W/ME383W/MC423W/MC393W/ME453X/MC453X.
