5. Using On-Screen Menu

[V position]

(Only for PC signal input)

On the premise that the relative position of both projector and the screen is set up right, you can move the image

vertical position, if the position of the projected image on the screen is deviated.

1) Press ▲ ▼ button to select [V position] menu.

2) Press <ENTER> button.

3) Press ▲ ▼ button to adjust image V position.

Adjustment range is from -5 to +5.

[H. size]

(Only for PC signal input)

You can adjust and reduce the interference caused by patterns of the projected vertical stripes.The following pro-

jected patterns may cause a circular pattern (Noise). Adjust the amount of interference to the minimum. Users can

point the clock to adjust images.

1) Press ▲ ▼ button to select [H. size] menu.

2) press <ENTER> button.

3) Press ▲ ▼ button to adjust H. size level .

Adjustment range is from -15 to +15.

[Aspect]

Adjust the image to ﬁt the screen size, while keeping aspect of input signal's unchanged.

Press < MENU > button on the remote controller or on the top control panel to display the OSD menu. Press ▲ ▼

button to select the Display menu, then Press <ENTER> or ▶ button.

1) Press ▲ ▼ button to select [ Aspect ] menu.

2) Press <ENTER> button.

3) Press ▲ ▼ button to select the required item.

Normal........... Use the maximum size to roject while keeping the aspect of input signal's unchanged.

Wide............... Project images at the aspect of 16: 9.

Full..................Project images to the maximum.

4:3...................Project images at the aspect of 4:3.

16:10...............Project images at the aspect of 16:10.

NOTE:

• Aspect: XGA(Normal/Wide/Full/16:10), WXGA/WUXGA(Normal/Wide/Full/4:3).

• Video signal only supports Normal/Wide.

H.size

...

Display

Auto PC adj.

Fine sync 0

H position

V position

Aspect Normal

Front

Upper left

Blue

Orientation

Menu position

Background display

System
