4
1. Introduction
AC Input
Connect the supplied power cord’s
three-pin plug here, and plug the
other end into an active wall outlet.
(→ page 10)
As the theft and dropping-off
prevention measure, fix on the
supplied strap.
Monaural Speaker (16 W)
Terminal Panel
(→ page 6)
Intake Vent / Filter Cover
(→ page 82, 88)
Built-in Security Slot ( )*
Security chain opening
Attach an anti-theft device.
The security chain opening accepts
security wires or chains up to
0.18 inch/4.6 mm in diameter.
Rear
* This security slot supports the MicroSaver
®
Security System.
Rear Remote Sensor
(→ page 8)
To Next Page
