10. Appendix

❺ Compatible Input Signal List

OSD Display

Source Speciﬁcation

RGB HDMI Video Resolution

"Pixel clock

(MHz)"

H-freq(KHz) V-freq(Hz)

NTSC

－

－ ○

NTSC

－

15.734 59.940

NTSC-443

－－ ○

NTSC 4.43

PAL-60

－－ ○

PAL60

PAL-M

－－ ○

PAL-M

PAL

－－ ○

PAL

－

15.625 50.000

PAL-N

－－ ○

PAL-N

SECAM

－－ ○

SECAM

720x480ｉ 60Hz ○ －－

720x480i 13.500 15.734 59.940

720x480ｉ 60Hz － ○ － 720（1440）x480i

27.000 15.734 59.940

720x576ｉ 50Hz ○ －－

720x576i 13.500 15.625 50.000

720x576ｉ 50Hz － ○ － 720（1440）x576i

27.000 15.625 50.000

7 720x483 60Hz

○ ○ －

720x483(480P) 27.000 31.469 59.940

8 720x576 50Hz

○ ○ －

720x576(576P) 27.000 31.250 50.000

9 1280x720p 60Hz

○ ○ －

1280x720p

74.250 45.000 60.000

○ ○ －

74.176 44.955 59.940

10 1280x720p 50Hz

○ ○ －

74.250 44.955 50.000

1920x1080ｉ 60Hz

○ ○ －

1920x1080i

74.250 33.750 60.000

○ ○ －

74.176 33.716 59.940

1920x1080ｉ 50Hz ○ ○ －

74.250 28.125 50.000

1920x1080p 24Hz

－ ○ －

1920x1080p

74.250 27.000 24.000

○ ○ －

74.176 26.970 23.980

1920x1080p 60Hz

○ ○ －

148.500 67.500 60.000

○ ○ －

148.352 67.433 59.940

15 1920x1080p 50Hz

○ ○ －

148.500 56.250 50.000

16 640x480,60Hz

○ ○ －

640x480

25.175 31.469 59.940

17 640x480,67Hz

○ ○ －

30.240 35.000 66.667

18 640x480,72Hz

○ ○ －

31.500 37.861 72.809

19 640x480,75Hz

○ ○ －

31.500 37.500 75.000

20 640x480,85Hz

○ ○ －

36.000 43.269 85.008

21 800x600,56Hz

○ ○ －

800x600

36.000 35.156 56.250

22 800x600,60Hz

○ ○ －

40.000 37.879 60.317

23 800x600,72Hz

○ ○ －

50.000 48.077 72.188

24 800x600,75Hz

○ ○ －

49.500 46.875 75.000

25 800x600,85Hz

○ ○ －

56.250 53.674 85.061

26 832x624,75Hz

○ ○ －

832x624 57.283 49.725 74.550

27 1024x768,60Hz

○ ○ －

1024x768

65.000 48.363 60.004

28 1024x768,70Hz

○ ○ －

75.000 56.476 70.069

29 1024x768,75Hz

○ ○ －

78.750 60.023 75.029

30 1024x768,85Hz

○ ○ －

94.500 68.678 84.997

31 1152x864,70Hz

○ ○ －

1152x864

94.200 63.995 70.020

32 1152x864,75Hz

○ ○ －

108.000 67.500 75.000

33 1280x720,60Hz

○ ○ －

1280x720 74.500 44.772 59.855

34 1280x768,60Hz

○ ○ －

1280x768

79.500 47.776 59.870

35 1280x768,75Hz

○ ○ －

102.250 60.289 74.893

36 1280x768,85Hz

○ ○ －

117.500 68.630 84.840

37 1280x800,60Hz

○ ○ －

1280x800

83.500 49.702 59.810

38 1280x800,75Hz

○ ○ －

106.500 62.795 74.934

39 1280x800,85Hz

○ ○ －

122.500 71.554 84.880

40 1280x960,60Hz

○ ○ －

1280x960

108.000 60.000 60.000

1280*960，75Hz ○ ○ －

126.000 75.000 75.080

Questions and Answers:

Need help?

Do you have a question about the NEC MC453X and is the answer not in the manual?

NEC MC453X Specifications

General

Native aspect ratio	4:3
Projection distance	0.9 - 10.9 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
RMS rated power	16 W
Number of built-in speakers	1
Placement	Ceiling, Floor
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	150 W
Service life of light source	10000 h
Service life of light source (economic mode)	20000 h
Built-in display	-
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	19.158 - 23.018 mm
Aperture range (F-F)	1.6 - 1.76
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	320 W
Power consumption (standby)	0.5 W
Power consumption (typical)	305 W
Power consumption (economy mode)	215 W
Power consumption (network standby)	2 W
Noise level	37 dB
Certification	UL, FCC Part15 Class B, CAN/CSA, ICES-003 Issue 6
Noise level (economic mode)	29 dB
Full HD	No
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	Not supported
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100 Mbit/s
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Remote control type	IR
