10. Appendix
No
OSD Display
Source Specification
RGB HDMI Video Resolution
"Pixel clock
(MHz)"
H-freq(KHz) V-freq(Hz)
42 1280x1024,60Hz
○ ○ －
1280x1024
108.000 63.981 60.020
43 1280*1024,65Hz
○ ○ －
118.500
65.180
44 1280x1024,72Hz
○ ○ －
135.060 78.16 71.97
45 1280x1024,75Hz
○ ○ －
135.000 79.976 75.025
46 1280x1024,85Hz
○ ○ －
157.500 91.146 85.024
47
1360*768，60Hz ○ ○ －
1360x768 85.500 47.710 60.020
48 1366x768,60Hz
○ ○ －
1366x768 84.750 47.720 59.799
49 1400x1050,60Hz
○ ○ －
1400x1050
121.750 65.317 59.978
50 1400x1050,75Hz
○ ○ －
156.000 82.278 74.867
51 1440x900,60Hz
○ ○ －
1440x900 106.500 55.935 59.887
52 1600x900,60Hz
○ ○ －
1600x900 118.998 55.920 60.000
53 1600x1200,60Hz
○ ○ －
1600x1200 162.000 75.000 60.000
54 1680x1050,60Hz
○ ○ －
1680x1050 146.250 65.290 59.954
55 1920x1080,60Hz
○ ○ －
1920x1080 138.500 66.587 59.934
56 1920x1200,60Hz
○ ○ －
1920x1200 154.000 74.038 59.950
57 3840x2160,30Hz
○ －
3840x2160 297 67.5 30.000
NOTE:
“○” Shows input signal source support this format.
“－” Shows input signal source DO NOT support.
－
