NEC MC453X User Manual

69
7. Installation and Connections
[MC393W]
Screen Size
B
C
D
α
Diagonal Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm - inch mm inch mm Degree - Degree
30 762 25 635 16 406 7 174 38 955 - 45 1149 -1 -29 10.3 - 8.6
40 1016 34 864 21 533 9 229 50 1277 - 60 1536 -2 -38 10.2 - 8.5
60 1524 51 1295 32 813 14 348 76 1922 - 91 2311 -2 -58 10.2 - 8.5
80 2032 68 1727 42 1067 18 457 101 2567 - 121 3086 -3 -77 10.2 - 8.5
100 2540 85 2159 53 1346 23 577 126 3211 - 152 3860 -4 -96 10.2 - 8.5
120 3048 102 2591 64 1626 27 697 152 3856 - 182 4635 -5 -115 10.2 - 8.5
150 3810 127 3226 79 2007 34 860 190 4823 - 228 5797 -6 -144 10.2 - 8.5
180 4572 153 3886 95 2413 41 1035 228 5790 - 274 6959 -7 -173 10.2 - 8.5
200 5080 170 4318 106 2692 45 1154 253 6435 - 304 7733 -8 -192 10.2 - 8.5
240 6096 204 5182 127 3226 54 1383 304 7725 - 365 9283 -9 -230 10.2 - 8.5
270 6858 229 5817 143 3632 61 1557 342 8692 - 411 10445 -10 -259 10.2 - 8.5
300 7620 254 6452 159 4039 68 1732 380 9659 - 457 11607 -11 -288 10.2 - 8.5
[MC423W]
Screen Size
B
C
D
α
Diagonal Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm - inch mm inch mm Degree - Degree
30 762 25 646 16 404 6 160 34 856 - 41 1046 -2 -42 10.6 - 8.7
40 1016 34 862 21 538 8 214 45 1153 - 55 1403 -2 -55 10.5 - 8.7
60 1524 51 1292 32 808 13 321 69 1748 - 83 2117 -3 -83 10.4 - 8.6
80 2032 68 1723 42 1077 17 428 92 2342 - 111 2831 -4 -111 10.3 - 8.6
100 2540 85 2154 53 1346 21 534 116 2937 - 140 3545 -5 -139 10.3 - 8.6
120 3048 102 2585 64 1615 25 641 139 3531 - 168 4260 -7 -166 10.3 - 8.6
150 3810 127 3231 79 2019 32 802 174 4423 - 210 5331 -8 -208 10.3 - 8.6
180 4572 153 3877 95 2423 38 962 209 5314 - 252 6402 -10 -250 10.3 - 8.5
200 5080 170 4308 106 2692 42 1069 233 5909 - 280 7116 -11 -277 10.3 - 8.5
240 6096 204 5169 127 3231 50 1283 279 7097 - 336 8544 -13 -333 10.2 - 8.5
270 6858 229 5816 143 3635 57 1443 315 7989 - 379 9615 -15 -374 10.2 - 8.5
300 7620 254 6462 159 4039 63 1603 350 8881 - 421 10686 -16 -416 10.2 - 8.5
[ME403U]
Screen Size
B
C
D
α
Diagonal Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm - inch mm inch mm Degree - Degree
30 762 25 646 16 404 6 154 29 745 - 49 1240 -2 -48 11.7 - 7.1
40 1016 34 862 21 538 8 206 40 1012 - 66 1670 -3 -64 11.5 - 7.0
60 1524 51 1292 32 808 12 309 61 1545 - 100 2532 -4 -95 11.3 - 6.9
80 2032 68 1723 42 1077 16 411 82 2079 - 134 3393 -5 -127 11.2 - 6.9
100 2540 85 2154 53 1346 20 514 103 2612 - 167 4254 -6 -159 11.1 - 6.9
120 3048 102 2585 64 1615 24 617 124 3145 - 201 5115 -8 -191 11.1 - 6.9
150 3810 127 3231 79 2019 30 771 155 3945 - 252 6407 -9 -238 11.1 - 6.9
180 4572 153 3877 95 2423 36 926 187 4745 - 303 7699 -11 -286 11.0 - 6.9
200 5080 170 4308 106 2692 40 1028 208 5278 - 337 8560 -13 -318 11.0 - 6.9
240 6096 204 5169 127 3231 49 1234 250 6345 - 405 10283 -15 -381 11.0 - 6.8
270 6858 229 5816 143 3635 55 1388 281 7145 - 456 11575 -17 -429 11.0 - 6.8
300 7620 254 6462 159 4039 61 1543 313 7945 - 507 12867 -19 -477 11.0 - 6.8

NEC MC453X Specifications

General

Native aspect ratio	4:3
Projection distance	0.9 - 10.9 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
RMS rated power	16 W
Number of built-in speakers	1
Placement	Ceiling, Floor
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	150 W
Service life of light source	10000 h
Service life of light source (economic mode)	20000 h
Built-in display	-
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	19.158 - 23.018 mm
Aperture range (F-F)	1.6 - 1.76
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	320 W
Power consumption (standby)	0.5 W
Power consumption (typical)	305 W
Power consumption (economy mode)	215 W
Power consumption (network standby)	2 W
Noise level	37 dB
Certification	UL, FCC Part15 Class B, CAN/CSA, ICES-003 Issue 6
Noise level (economic mode)	29 dB
Full HD	No
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	Not supported
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100 Mbit/s
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Remote control type	IR

Weight and Dimensions

Depth	261 mm
Width	345 mm
Height	108.4 mm
Weight	3300 g
Package depth	390 mm
Package width	450 mm
Package height	200 mm
Package weight	4700 g
