5. Making Connections
92
5-5. Connecting to a HDBaseT transmission device (sold commercially)
HDBaseT is a connection standard for home appliances that is established by the HDBaseT Alliance.
Use a LAN cable sold commercially to connect the Ethernet/HDBaseT port of the projector (RJ-45)
to a HDBaseT transmission device sold commercially.
The Ethernet/HDBaseT port of the projector supports HDMI signals (HDCP) from transmission devices,
serial control from external devices, and remote control signals (IR commands).
Connection example
Ethernet/HDBaseT
Computer (for control use)
Computer (for output use)
Example of a transmission device
Remote control
HDMI output video device
To Next Page
