3. Convenient Features
40
5. Press the ▼ button to select [CORNER-
STONE] and press the ENTER button.
The [CORNERSTONE] screen will be displayed.
* The drawing shows the upper left icon ( )
is selected.
6. Project an image so that the screen is
smaller than the area of the raster.
Projected image
7. Pick up any one of the corners and align
the corner of the image with a corner of the
screen.
* The drawing shows the upper right corner.
8. Use the ▲▼◀▶ button to select one icon
(▲) which points in the direction you wish
to move the projected image frame.
TIP:
• If either [CORNERSTONE] or [PINCUSHION] is adjusted, the
options [KEYSTONE VERTICAL] and [KEYSTONE HORIZON-
TAL] become unavailable. In this case, RESET the corrected
values and restart to correct distortion.
9. Press the ENTER button.
10. Use the ▲▼◀▶ button to move the project-
ed image frame as shown on the example.
11. Press the ENTER button.
12. Use the ▲▼◀▶ button to select another
icon which points in the direction.
On the Cornerstone adjustment screen, select
[EXIT] or press the EXIT button on the remote
control.
The conrmation screen is displayed.
To Next Page
