ROI-S04604 SYSTEM CONFIGURATION
2-1
2. SYSTEM CONFIGURATION
This system consists of TRP-[ ]G-[ ] Transmitter-Receiver (Outdoor Unit
(ODU)) (see Fig. 2-1) and MDP-[ ]MB-[ ] Modulator-Demodulator
(Indoor Unit (IDU)) (see Fig. 2-2 and Fig. 2-3 ).
The [ ]GHz (2/4/8/16 x 2 MB) MB digital radio system is used to
communicate from 2 to 16 data streams at 2.048 Mbps and/or up to 2
channels 10BASE-T/100BASE-TX LAN signals between two stations.
The system block diagrams of 2/4/8/16 x 2 MB systems are shown in Fig.
2-4 and Fig. 2-5.
Fig. 2-1 Outline of ODU
FOR 7-38 GHz BAND ODU
FG
IFL
MON
RX LEV
