ROI-S04604 SYSTEM PERFORMANCE
3-1
3. SYSTEM PERFORMANCE
The system performance is listed in Table 3-1.
Table 3-1 Performance Characteristics
ITEM 7 GHz 8 GHz 13 GHz 15 GHz 18 GHz 23 GHz 26 GHz 38 GHz GUARANTEED
Frequency
Range [ GHz]
7.125-
7.725
7.900-
8.500
12.75-
13.25
14.5-
15.35
17.7-
19.7
21.2-
23.6
24.5-
26.5
37.0-
39.5
Frequency
Plan ITU-R
F.385-6 F.386-6
Annex 4
F.497-6 F.636-3 F.595-7 F.637-3 F.748-4 F.749-2
Channel
Separation
3.5 MHz (4MB) / 7 MHz (8 MB) / 14 MHz (17 MB; 13.75 MHz also for 18 GHz) /
28 MHz (34 MB; 27.5 MHz also for 18 GHz)
RF TX/RX
Spacing [MHz]
154
161
126
266
266 315
420
490
728
340
1008
1010
1560
1008
1200
1232
1008 1260
Output Power at
Antenna Port
[dBm]
+27 +25 +23 +23 +23 +20 +15 ±1.5 dB
(ATT=0)
Threshold Level
(dBm measured
at antenna port)
BER=10
-3
4 MB
-93.5 -93.5 -93.5 -92.5 -91.5 -91.0 -90.5 +2.5 dB
8 MB -90.5 -90.5 -90.5 -89.5 -88.5 -88.0 -87.5 +2.5 dB
17 MB -87.5 -87.5 -87.5 -86.5 -85.5 -85.0 -84.5 +2.5 dB
34 MB -84.5 -84.5 -84.5 -83.5 -82.5 -82.0 -81.5 +2.5 dB
BER=10
-6
4 MB
-90.0 -90.0 -90.0 -89.0 -88.0 -87.5 -87.0 +2.5 dB
8 MB -87.0 -87.0 -87.0 -86.0 -85.0 -84.5 -84.0 +2.5 dB
17 MB -84.0 -84.0 -84.0 -83.0 -82.0 -81.5 -81.0 +2.5 dB
34 MB -81.0 -81.0 -81.0 -80.0 -79.0 -78.5 -78.0 +2.5 dB
System gain
(dBm measured
at ant. port)
BER=10
-3
4 MB
120.5 118.5 116.5 115.5 114.5 111.0 105.5 -4.0 dB
8 MB 117.5 115.5 113.5 112.5 111.5 108.0 102.5 -4.0 dB
17 MB 114.5 112.5 110.5 109.5 108.5 105.0 99.5 -4.0 dB
34 MB 111.5 109.5 107.5 106.5 105.5 102.0 96.5 -4.0 dB
BER=10
-6
4 MB
117.0 115.0 113.0 112.0 111.0 107.5 102.0 -4.0 dB
8 MB 114.0 112.0 110.0 109.0 108.0 104.5 99.0 -4.0 dB
17 MB 111.0 109.0 107.0 106.0 105.0 101.5 96.0 -4.0 dB
34 MB 108.0 106.0 104.0 103.0 102.0 98.5 93.0 -4.0 dB
