NEC PASOLINK installation procedure
January 2002
Mounting of IDU.
Mounting of ODU and ANT.:
There are two diffwerent cases as follows:
1- The ODU is direct mounted to the antenna.
2- The ODU is mounted with a separate bracket.
According to which case you have ,you will follow the assempling procedure included with each antenna
And you will know how to fix that ODU.
Note:
In case two you have to install an additional RF cable between the ODU and the Antenna.
The tools required:
Wrench, Monkey wrench or Torque wrench , and suitable screwdriver.
ODU Demounting (if necessary):
1- Remove the four fixed bolts from the ODU.
2- Then demount the ODU.
