ROI-S04488 OPERATION
3-57
3.4.3 Monitoring the ODU
The following items of the ODU can be monitored on the PC.
• Transmitter output power
• Received signal level
The procedure is as follows:
Step Procedure
1 Connect the personal computer (PC) to the LA PORT of the
IDU using an RS-232C cable as shown in Fig. 3-7,
2 Turn on the power on the PC. Then, operate the communication
software (e.g. MS Hyper Terminal),
3 Press the “CTRL” and “D” keys at the same time,
4 Enter the specified password from the keyboard and press the
“Enter” key,
5 Press the “0” key and “Enter” key,
6 Following menu items are displayed,
Password :
Password :
********
Change password? (no:0 / yes:1) :
1. Setting
2. Maintenance
3. Monitoring
99. Exit
Select function No. :
To Next Page
