NEC PASOLINK - Page 109

OPERATION ROI-S04488
3-58
Step
Procedure
7 Press the “3” key and “Enter” key, then, following menu is
displayed,
For 1+0 System
For 1+1 System
8 Press the “1” key and “Enter” key, then, following item is
displayed,
Note: The voltages shall be indicated within the values shown in
Table 3-4 in normal,
For 1+0 System
For 1+1 System
Monitoring
1. Monitoring voltage
2. Monitoring voltage (Continuance mode)
3. Alarm/Status
4. Inventory
00. Menu
99. Exit
Select item No. :
Monitoring
1. Monitoring voltage
2. Alarm/Status
3. Inventory
00. Menu
99. Exit
Select item No. :
1. Monitoring voltage
Transmitter power : 4.33V (-1 dB)
Receiving level : 3.55V (-32 dBm)
1. Monitoring voltage
Transmitter power 1 : 4.33V (-1 dB)
Receiving level 1 : 2.98V (-46 dBm)
Transmitter power 2 : 4.33V (-1 dB)
Receiving level 2 : 2.18V (-66 dBm)
