ROI-S04488 OPERATION
3-59
Step
Procedure
9 Press the “Esc” key to go back to the Monitoring menu, then,
enter 99 to exit the monitoring of the Pasolink.
For 1+0 System
For 1+1 System
Notes:1. *1 The code number of bit rate free type ODUs are as follows:
• G2924 • G3359 • G5380 • G5383
• G5384 • G6594
• H0330 • H0331 • H0332 • H0333
• H0334 • H0335
2. *2 The code number of fixed bit rate type 7/8 GHz ODUs are
as follows:
• G6583 • G6584 • G6585 • G6586
• H0738 • H0739
Monitoring
1. Monitoring voltage
2. Monitoring voltage (Continuance mode)
3. Alarm/Status
4. Inventory
00. Menu
99. Exit
Select item No. :
Monitoring
1. Monitoring voltage
2. Alarm/Status
3. Inventory
00. Menu
99. Exit
Select item No. :
Table 3-4 Meter Reading of IDU and ODU
CHECK ITEM ALLOWABLE RANGE
Transmitter power Depends on transmitter power
• 0 to 4.6 V DC (Bit rate free type ODU*1)
• 0 to 4.6 V DC (Fixed bit rate type 7/8 GHz ODU*2)
Receiving level Depends on received signal level
• 0.8 to 4.4 V DC (Bit rate free type ODU*1)
• 0.8 to 4.4V DC (Fixed bit rate type 7/8 GHz ODU*2)
