ROI-S04605 OPERATION
3-1
3. OPERATION
This chapter provides instructions for operating the ODU. Included are
information on the interface terminals, interface jacks, controls, indicators,
test jacks, equipment start-up, and equipment shut-down.
3.1 Interface Terminals and Jacks
The equipment has interface terminals and jacks to connect with the
associated equipment. These interface terminals and jacks are located as
shown in Fig. 3-1 and are used as described in Table 3-1.
Fig. 3-1 Interface Terminal and Jack Locations
7-38 GHz Band ODU
(FG)
IF IN/OUT
(FRONT VIEW)
FG
IFL
MON
RX LEV
13-38 GHz Band ODU
RF IN/OUT
(REAR VIEW)
7/8 GHz Band ODU
RF IN/OUT
(REAR VIEW)
