NEC PE506UL - ❺ Compatible Input Signal List

99
10. Appendix
❺ Compatible Input Signal List
No OSD Display
Source Specification
RGB HDMI Resolution
Pixel clock
(MHz)
H-freq(KHz) V-freq(Hz)
1 720x480i 60Hz
○ -
720x480i 13.500 15.734 59.940
2 720x576i 50Hz
○ -
720x576i 13.500 15.625 50.000
3 720x480i 60Hz
- ○
720 (1440) x480i 27.000 15.734 59.940
4 720x576i 50Hz
- ○
720 (1440) x576i 27.000 15.625 50.000
5 720x483 60Hz
○ ○
720x483(480P) 27.000 31.469 59.940
6 720x576 50Hz
○ ○
720x576(576P) 27.000 31.250 50.000
7 1280x720p 60Hz
- ○
1280x720p
74.250 45.000 60.000
○ ○
74.176 44.955 59.940
8 1280x720p 50Hz
- ○
74.250 37.500 50.000
9 1920x1080i 60Hz
○ ○
1920x1080i
74.250 33.750 60.000
○ ○
74.176 33.716 59.940
10 1920x1080i 50Hz
○ ○
74.250 28.125 50.000
11 1920x1080p 24Hz
○ ○
1920x1080p
74.250 27.000 24.000
○ ○
74.176 26.970 23.980
12 1920x1080p 60Hz
○ ○
148.500 67.500 60.000
○ ○
148.352 67.433 59.940
13 1920x1080p 50Hz
○ ○
148.500 56.250 50.000
14 640x480,60Hz
○ ○
640x480 25.175 31.469 59.940
15 800x600,56Hz
○ -
800x600 36.000 35.156 56.250
16 1024x768,60Hz
○ ○
1024x768 65.000 48.363 60.004
17 1280x720,60Hz
○ ○
1280x720 74.500 44.772 59.855
18 1280x768,60Hz
○ ○
1280x768 79.500 47.776 59.870
19 1280x800,60Hz
○ ○
1280x800 83.500 49.702 59.810
20 1280x960,60Hz
○ ○
1280x960
108.000 60.000 60.000
21 1280x960,75Hz
○ -
126.000 75.000 75.080
22 1280x1024,60Hz
○ ○
1280x1024 108.000 63.981 60.020
23 1366x768,60Hz
○ ○
1366x768 85.500 47.712 59.790
24 1400x1050,60Hz
○ ○
1400x1050 121.750 65.317 59.978
25 1440x900,60Hz
○ ○
1440x900 106.500 55.935 59.887
26 1600x1200,60Hz
○ ○
1600x1200 162.000 75.000 60.000
27 1680x1050,60Hz
○ ○
1680x1050 146.250 65.290 59.954
28 1920x1080,60Hz
○ ○
1920x1080 148.500 67.500 60.000
29 1920x1200,60Hz
○ ○
1920x1200 154.000 74.038 59.950
30 3840x2160,30Hz
- ○
3840x2160 297.000 67.500 30.000
NOTE:
“○” Shows input signal source support this format.
“-” Shows input signal source DO NOT support.
