7. Installation and Connections
[PE456USL/PE456WSL]
Screen surface
Approximately 82 mm
Lens center
Projection distance L
Height H
(NOTE) Height from lens center to lower edge of screen (with tilt feet screwed in)
Screen size
(inches)
Throw distance L Height H
(m) (inches) (cm) (inches)
55 0.52 20.37 74.04 29.15
60 0.57 22.34 80.77 31.80
70
0.67 26.28 94.23 37.10
80 0.77 30.22 107.70 42.40
90 0.87 34.16 121.16 47.70
100 0.97 38.09 134.62 53.00
130 1.27 49.91 175.01 68.90
