The output is shown similar to that of an ISDN Layer 3 analyzer:
SEND PORT = 4C001FH
S ISDN : >>>>>>>>>>>>>>>>>>>>
11 A1 11 02 01 00
08 01 84 0D
18 01 89
1e 02 82 88
USL (3,2) SETUP ACK REQ
Callref: DES (4), SETUP ACKNOWLEDGE
Channel identification [B1 channel (exclusive)]
Progress indicator
Example shown above:
4C001FH
The logical port type and number of the ISDN circuit on the SV 9100. 4C indicates S-point port type (see
reading traces later in this manual) 001F is the port number in hexadecimal
S ISDN : >>>>>>>>>>>>>>>>
The direction of the event. S >>> indicates Send, R <<< indicates Receive.
USL(3,2),
The slot and circuit number of the ISDN card that the event was sent/received on.
If you have more than one ISDN card in the system, the slot and circuit number can be identified by this
information.
The first number is the slot number in decimal (3 in this example). The second number is the circuit in
decimal (2 in this example).
The remainder of the information is appropriate to the type of message and is similar to an ISDN analyzer.
