SECTION 10 READING SV9100 DIM TRACES
The DIM trace can be partly decoded by the engineer but only NEC Infrontia Japan can decode the
full trace.
This section describes the basic decode to enable the engineer to identify the extension and trunk port
number.
o Extensions
Each extension type has a unique logical port type as shown below.
Type
Logical ID
Key telephone
0004
SLIU
0000
S-Point
004c
DECT
00e9
The port number is identified by the four digits (in hexadecimal) following the logical port type. The four
digits are 0000 to ffff hexadecimal (00 to 65535 in decimal).
(example: keytelephone port 1 will be 00040001 as shown below.)
>>>> PORT : 0401H STATUS 0000H => 0002H
o Trunks
Each trunk type has a unique logical port type as shown below.
Type
Logical ID
COIU
000c
ISDN
0034
The port number is identified by the four digits (in hexadecimal) following the logical port type. The four
digits are 0000 to ffff hexadecimal (00 to 65535 in decimal).
(example: ISDN port 17 will be 00340011 as shown below.)
>>>> PORT : 00340011H STATUS 00D0H => 00B1H
