NEC Univerge SV9100 - Page 70

Issue 1.0
UNIVERGE SV9100
58
System Maintenance Manual
R ISDN : <<<<<<<<<<<<<<<<
11 0B A1 02 01 01 00 USL(8,1),CALL PROCEEDING IND
08 02 80 03 02 Callref:DES(3),CALL PROCEEDING
18 03 A9 83 81 Channel identification
PHYSICAL_W =0108HR ISDN : <<<<<<<<<<<<<<<<
15 0B A1 01 01 01 00 USL(8,1),ALERTING IND
08 02 80 03 01 Callref:DES(3),ALERTING
18 03 A9 83 81 Channel identification
1E 02 81 81 Progress indicator
PHYSICAL_W =0108HR ISDN : <<<<<<<<<<<<<<<<
13 0B A1 30 01 01 00 USL(8,1),SETUP CONF
08 02 80 03 07 Callref:DES(3),CONNECT
29 05 04 08 02 09 39 Date/Time [04. 8. 2 9:57]
ITR_CINT_STUPCNF: DES_ANSWER_FLAG SET!
ITR_CINT_STUPCNF: TM_DES_ANSWER_WAIT_L CANCEL!
ACD Data Size error. or socket close... 9:57:07 >>
R ISDN : <<<<<<<<<<<<<<<<
14 0B A1 09 01 01 00 USL(8,1),DISCONNECT IND
08 02 80 03 45
Callref:DES(3),DISCONNECT
08 02 80 90 Cause (16)
1E 02 81 88 Progress indicator T305 TIMER CLEAR !!!
ACD Data Size error. or socket close..
HP_LCD_REQ(00040001,00000001,00000000,00000000,00000000).
ACD Data Size error. or socket close...
S ISDN : >>>>>>>>>>>>>>>>
F4 A1 0C 01 01 00 USL(8,1),RELEASE REQ
08 02 00 03 4D Callref:ORG(3),RELEASE
08 02 80 90 Cause (16)
R ISDN : <<<<<<<<<<<<<<<<
0C 0B A1 33 01 01 00 USL(8,1),RELEASE CONF
08 02 80 03 5A Callref:DES(3),RELEASE COMPLETE
305 TIMER CLEAR !!!
t310_timer_cancel() hunt_que_del_allstg des_w[3415]
Tone information for port 000C0015H
Timeslot : 0138H
Level : Tx=20H, Rx=20H
Current : 00F2H Level=20H
Sender : Not opened
ACD Data Size error. or socket close...
Network returns Call
Proceeding.
Network returns Alerting.
Called party is now ringing.
Network returns Connect when
called party answers.
This may also include the
date/time.
Network returns Disconnect
when called party hangs up.
Cause 16 is ‘Normal call
clearing’.
SV9100 sends release to
indicate
channel can be released.
Network returns
Release Complete.
Channel is now free.
