Using the Hardware 2-7
Inserting the battery pack
5. Replace the battery bay cover as follows:
■ Align the tabs on the battery cover with the notches
in the system.
■ Lower the cover onto the system.
■ Slide the cover towards the middle of the unit. Tuck
the tabs on the back of the cover under the chassis.
Replacing the cover
Notched End
Terminals
Tab
Notch
Tabs (not shown)
Notch
