Hangzhou NeoDen Technology Co.,Ltd.
(1) Support pick up simultaneously: Check this to make the nozzles with the same pick height
picking the components simultaneously. This will raise the mounting speed much more.
(2) Support step subdivide: Check this to subdivide steps to nozzles
(3) Rail continuous mounting: Check this to make the rail feeding boards automatically, which
will make the whole process continuously.
(4) Log level：The higher the log level, the more information will be collected
(5) Rail raise PCB: Click this after finish mounting, the rail roof cylinder will jack-up or
drop-down.
Exit, click ‘stop’ then click ‘exit’ to finish mounting, exit the mounting interface.
2.3 Factory settings
Function: this part arm at machine’ global parameter settings, any modified parameter will
influence all mounting files, when modify this part please consider seriously. Especially the
last page system settings, we suggest after using a period of time or under the guidance of our
engineers then change its parameter. (Notice, before our machines leave factory, all parameter
already be set and no need to change). This user manual just introduces all setting functions
briefly, more details about parameter modification please refer to comments from our
engineers.
Figure (2.4)
●Shown as figure 2.4 , function description of button on right side
●Save configuration: click it for saving after modify the parameters
●Modify password: click it, put into the password, then finish change the fourth page which is
also the system interface.
● Version upgrade: Our software version is upgrading constantly. After receiving our new
version file, you can upload it with clicking ‘version upgrade’ to finish.
●English：NeoDen7 support English and Chinese, click this button can change the language
