NeoDen7 User Manual
(High-Speed Fully Automatic Pick and Place machine)
1.Brief Introduction
1.1 Product Introduction
The seventh-generation model NeoDen7(Automatic universal visual pick and place machine)
is NeoDen Tech’s independent product, with completely independent intellectual property.
NeoDen7 has the advantages of fast speed, high accuracy, convenient operation, multiple
feeders, high efficiency, stable performance, convenient and simple operation. NeoDen7
features six independent flying HD cameras, one IC alignment camera and one independent
fiducial camera, perfectly implements standard mounting of components such as
micro-miniature components and fine-pitch IC under the premise of ensuring efficient
mounting; NeoDen7 adopts the most stable pneumatic feeder on the market, the advantages are
stability, easy replacement, easy installation, quick and convenient tape reel installation, it
matching with vision correction system and rail feeding system.
Maximum Board
Dimension
630*300mm（1200mm optional)
Number of Heads
Placement head:1 Nozzle:6
Max Tape Feeder
Capacity
64(8mm or 12mm feeder)
Applicable tape reel
feeder size
8mm,12mm,16mm,24mm,32mm,44mm,56mm
Average Placement
Speed
13,500CPH
Vision Number
8(1 fiducial camera, 6 flying cameras, 1 IC camera)
Component range
Smallest components:0402, TQFP, QFN, BGA and other
conventional components
Feeder Number
Tape feeder:64
Resolution
X/Y axis:0.01mm, Z axis:0.1mm
Rotation
±180°（360°）
Placement Accuracy
0.01mm
Power Supply
AC220V/110V
Power
500W
Machine Size
1420*1220*1665mm
Air Source
Above 0.6MP
