N720 OpenLinux

Hardware User Guide

Figure 3-6 Reference design of startup controlled by button

ESD

N720

module

PWRKEY_N

1kΩ

Figure 3-7 Reference design of startup controlled by MCU

N720

module

PWRKEY_N

USER_ON

Figure 3-8 Reference design of automatic start once powered up

1.5 kΩ

N720

module

PWRKEY_N

Startup Process

After powering up the VBAT pin, input a negative pulse of wider than 100 ms (longer than 200 ms is
