Neoway N720 OpenLinux - GNSS Feature

N720 OpenLinux
Hardware User Guide
Copyright © Neoway Technology Co., Ltd
72
FDD-LTE B3
<-95 dBm
FDD-LTE B4
<-97 dBm
FDD-LTE B5
<-95 dBm
FDD-LTE B7
<-95 dBm
FDD-LTE B8
<-95 dBm
FDD-LTE B12
<-95 dBm
FDD-LTE B17
<-95 dBm
FDD-LTE B20
<-95 dBm
FDD-LTE B28A
<-95 dBm
FDD-LTE B28B
<-95 dBm
TDD-LTE B38
<-97 dBm
TDD-LTE B39
<-97 dBm
TDD-LTE B40
<-97 dBm
TDD-LTE B41
<-95 dBm
All values above were obtained in the lab. In actual applications, there might be a difference
because of network environments.
5.3 GNSS Feature
Changes
Parameter
GPS L1 operating frequency
1575.42±1.023 MHz
GLONASS operating frequency
1597.5~1605.9 MHz
BDS operation frequency
1559.1~1563.1 MHz
Tracking sensitivity
-160 dBm (GPS)/-159.5 dBm (GLONASS)/TBD (BDS)
Acquisition sensitivity
-144 dBm (GPS)/-143.5 dBm (GLONASS)
Positioning precision (in air)
< 3 m (CEP50)
Hot start (in air)
<2.5s
Cold start (in air)
<35s
Update frequency
1Hz by default
