CNRin/CNRout

3dB

Max. positioning altitude

18000m

Max. positioning speed

515 m/s

Max. positioning acceleration

GNSS data type

NMEA-0183

GNSS antenna type

Passive/active antenna

Tracking sensitivity, acquisition sensitivity, and re-acquisition sensitivity were obtained in signaling

test on SPIRENT6300 and they are the maximum values of multiple tests on samples. No external LNA

or active antenna was used in the test.
