N720 OpenLinux

Hardware User Guide

Figure 3-18 Recommended level shifting circuit 1

MCU_RXD

MCU_TXD

UART_TXD

VDD_1P8

VCC_IO

4.7kΩ

10kΩ

VDD_1P8 VCC_IO

4.7kΩ

10kΩ

MCU_RXD

If the low level at MCU_UART (V

) is lower than 200mV, adopt recommended level shifting circuit 2.

Otherwise, low level at UART might be higher than required, resulting in failure to identify signals.
