N720 OpenLinux

Hardware User Guide

6.2 Label

The label is made of materials that are deformation-resistant, fade-resistant, and high-temperature-

resistant and it can endure high temperature up to 260 °C.

Figure 6-2 N720 Openlinux label

 The picture above is only for reference.

 The silk-screen printing must be clear. No blur is allowed.

 The material and surface finishing must comply with RoHS directives.

6.3 Pack

N720 OpenLinux modules are packaged in sealed vacuum bags with dryer, humidity card, and tray on

delivery to guarantee a long shelf life. Follow the same package method again in case of opened for

any reasons.
