N720 OpenLinux

Hardware User Guide

6.3.2 Moisture

N720 OpenLinux is a level 3 moisture-sensitive electronic elements, in compliance with IPC/JEDEC J-

STD-020 standard.

If the module is exposed to air for more than 48 hours at conditions not worse than 30°C/60% RH,

bake it at a temperature higher than 90 degree for more than 12 hours before SMT.Or, if the indication

card shows humidity greater than 20%, the baking procedure is also required.Do not bake modules

with the package tray directly.
