N720 OpenLinux
Hardware User Guide
Copyright © Neoway Technology Co., Ltd
viii
About This Document
Scope
This document is applicable to N720 OpenLinux series.
It defines the features, indicators, and test standards of the N720 OpenLinux module and provides
reference for the hardware design of each interface.
Reference designs in this document are only for reference. Customers should design applications
based on the actual scenarios and conditions.Please contact Neoway FAE if you have any question or
doubt.
Audience
This document is intended for system engineers (SEs), development engineers, and test engineers.
Change History
Issue
Date
Change
Changed By
1.0
2017-02
Initial draft
Dong Liuting
1.1
2017-04
 Updated pin definition and description

Modified the description of reset pin
Updated internal connection of GPS
Dong Liuting
1.2
2017-07
 Added LTE B12 for NA variant
 Added memory and size tolerance
 Modified the description of PWRKEY, RESET, UART,
and VDDIO_1P8
 Added MUX description of some pins

Modified description
Dong Liuting
1.3
2018-01
 Updated variants and bands
 Added GNSS features
 Added description of SGMII, WLAN, and SD
interfaces
Dong Liuting
