Neoway N720 - Features; Figure 1-1 N720 Block Diagram; Table 1-1 N720 Baseband and Wireless Features

N720 Hardware User Guide
Copyright © Neoway Technology Co., Ltd 3
Figure 1-1 N720 block diagram
VBAT
Power
Manager
RF transceiver
MCP
19.2 M
crystal
RF Section
Base Band
I2C
Digital Interface
USBUART
SIM
PC
ANT_MAIN
ANT_AUX ANT_GNSS
PWRKEY
RESET
ADC
UIM
PCM SDIO
1.3 Features
Table 1-1 N720 baseband and wireless features
Specifications
Description
Power supply
VBAT: 3.3V to 4.3V; Typical value: 3.8 V
Current in sleep mode
< 4 mA
Standby current
< 20 mA
Operating temperature
-40 °C to +85 °C
Processor
ARM Cortex-A7 processor
Main frequency: 1.3 GHz
256 kB L2 cache
