N720 Hardware User Guide
Copyright © Neoway Technology Co., Ltd 5
2 Application Interfaces
N720 adopts 100-pin LGA encapsulation package.
2.1 Specifications and Pin Definition
Table 2-1 N720 dimensions
Specifications
N720
Dimensions (H x W x D)
28±0.1 mm x 30±0.1 mm x 2.8±0.1 mm
Weight
5.1 g
Package
100-pin LGA
Figure 2-1 N720 module pin definition (Top View)
