N720 Hardware User Guide
Copyright © Neoway Technology Co., Ltd 11
Imax=20mA
Leave this pin unconnected if it is not used.
SDIO_CMD
54
IO
SDIO IO control
signal
V
IL
max = 0.6V
V
IH
min = 1.3V
V
OL
max = 0.45V
V
OH
min = 1.4V
1.8V
Leave this pin unconnected if it is not used.
SDIO_CLK
55
DO
SDIO clock signal
1.8V
Leave this pin unconnected if it is not used.
SDIO_DATA_0
56
IO
SDIO data
output/input
V
IL
max = 0.6V
V
IH
min = 1.3V
V
OL
max = 0.45V
V
OH
min = 1.4V
1.8V
Leave this pin unconnected if it is not used.
SDIO_DATA_1
57
IO
SDIO data IO
V
IL
max = 0.6V
V
IH
min = 1.3V
V
OL
max = 0.45V
V
OH
min = 1.4V
1.8V
Leave this pin unconnected if it is not used.
SDIO_DATA_2
58
IO
SDIO data IO
V
IL
max = 0.6V
V
IH
min = 1.3V
V
OL
max = 0.45V
V
OH
min = 1.4V
1.8V
Leave this pin unconnected if it is not used.
SDIO_DATA_3
59
IO
SDIO data IO
V
IL
max = 0.6V
V
IH
min = 1.3V
V
OL
max = 0.45V
V
OH
min = 1.4V
1.8V
Leave this pin unconnected if it is not used.
WAKE_ON_WIRELESS
60
DO
WLAN mode control
signal
V
OL
max=0.45V
V
OH
min=1.35V
1.8V
Leave this pin unconnected if it is not used.
WLAN_SLEEP_CLK
61
DO
WIFI sleep clock
1.8V
Leave this pin unconnected if it is not used.
