ProCoder™)R900i™ Installation and Maintenance Guide 7
Chapter 3: Reading the ProCoder™)R900i™
This chapter provides information on reading the ProCoder™)R900i™.
How to Read
Become familiar with the information available from the meter.
Figure 4 – ProCoder™ Face and Sweep Hand
The sensitive sweep hand provides a visual representation of extreme low flows as well
as reverse flows. Depending on the size and type of ProCoder register, a specific
multiplier is present. This multiplier, along with the current position of the sweep hand,
provides additional digits of resolution that are especially useful for testing.
For further information on reading the ProCoder sweep hand, see the Product
Support Document How to Read the Neptune ProCoder™ Register.
