Connecting the ProCoder™)R900i ™ Through-the-Lid Antenna
When ordering an external antenna for the ProCoder)R900i unit, Neptune
recommends at least a 6-foot cable to allow for easy removal of the pit lid when
necessary.
Figure 6 – ProCoder™)R900i™ Antenna
Installing the Antenna
To install the antenna, complete the following steps.
1. Insert the antenna cable and housing through the 1¾-inch hole in the meter pit lid.
Figure 7 – Through-the-Lid Antenna
14 ProCoder™)R900i™Installation and Maintenance Guide
Chapter 4: Installing the ProCoder™)R900i™
