2. Thread the locking nut onto the antenna (smooth end towards lid).
Figure 8 – Locking the Nut on the Antenna
3. Hand tighten the nut securely to the lid.
Figure 9 – Securing the Locking Nut
Figure 10 shows a completed installation of the antenna.
Figure 10 – Installation Complete
ProCoder™)R900i™ Installation and Maintenance Guide 15
Chapter 4: Installing the ProCoder™)R900i™
