Neptune E-CODER User Manual

2: Product Description
The face of the E-CODER
®
contains reading
information.
Figure 1: E-CODER
®
Face Plate
3: Wiring the Inside Set Version
Follow these steps to run a three-conductor cable
from the E-CODER
®
register to the MIU.
1. Connect the three-conductor wire to the encoder
register’s terminals as described in the
manufacturer’s instructions, using the color code
in step 3. The encoder terminal uses three wires:
black, green, and red.
- 4 -

Neptune E-CODER Specifications

General

Output	Digital
Power Source	Battery or external power
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Power Supply	3.6V Lithium Battery
Dimensions	Varies depending on model
Weight	Varies depending on model
