Mounting the Gateway
To mount the gateway to a pole or stand, complete the following steps.
Figure 40 – Mounting Bracket
1. Position the gateway so that the top of the box is approximately level with the battery
box.
2. Attach the gateway to the pole using two stainless steel clamps.
Figure 41 – Positioning the Gateway
36 R900
®
Gateway Installation and Maintenance Guide
Chapter 4: Install the Gateway
