INTELLIGENT REACTIVE POWER MANAGEMENT
RM-12P
16
If one or more phase voltage value exceeds preset voltage value,an alarm
occurs at the end of adjusted delay time. Delay time can be set between
0-250 seconds.
3.9.a.b Over Voltage Delay Time Setting
SAUE
If you do not want to set another parameter, in order to quit from the
menu, press ESC button one by one until SAVE SEt yES is displayed.
Press SET button to save your changes or press ESC button to quit
without saving.
Press SET button for over voltage (SP-H) settings.
Enter the over voltage value between 0-300 V and if you want to set another
parameter, press SET button otherwise press ESC button.
Note : If over voltage value is set as 0, this function is disabled.
Press DOWN button to set over voltage delay time (dELy) menu.
3.9.a.c Switch On&Off Setting for Over Voltage
Alarm Setting
Press SET button to set delay time.
SAUE
If you do not want to set another parameter, in order to quit from the
menu, press ESC button one by one until SAVE SEt yES is displayed.
Press SET button to save your changes or press ESC button to quit
without saving.
Enter the over voltage delay time between 0-250 seconds and if you want
to set another parameter press SET button otherwise press ESC
button.
Press DOWN button, in order to pass from over voltage menu to the
over voltage step (StEP) menu.
In order to protect the capacitors from over voltage, when an over voltage
alarm occurs, capacitors switch on&off settings are done in this menu.
If on is selected, when over voltage error occurs, capacitor steps
switch on.
If off is selected, when over voltage error occurs, capacitor steps
switch off.
