Neptune RM-12P - Fan Relay Settings

If you do not want to set another parameter, in order to quit from the
menu, press ESC button one by one until SAVE SEt yES is displayed.
Press SET button to save your changes or press ESC button to quit
without saving.
INTELLIGENT REACTIVE POWER MANAGEMENT
RM-12P
22
SAUE
By UP/DOWN buttons, select on (capacitors switch on) or of
(capacitors switch off) option and press SET button. If you do not want
to set another parameter, press ESC button.
Switching-on and Switching-off values are defined in this menu. There are
two submenus as FAn on and FAn oFF for this feature.
Note: RM-12P temperature measurement feature is optional.
3.10 Fan Relay Settings
3.10.a Fan Relay Switched-on Value
Fan relay operating temperature is defined in this menu. Relay is switched
on after 10 sec. when the measured temperature increase the set value
and Fan led light will be on.
First parameter is the operating temperature of the fan. Press SET button
to enter the settings.
Press SET button to program the operating temperature.
Press SET button to enter the temperature alarm between 00.0-99.8 °C.
SAUE
If you do not want to set another parameter, in order to quit from the
menu, press ESC button one by one until SAVE SEt yES is displayed.
Press SET button to save your changes or press ESC button to quit
without saving.
3.10.b Fan Relay Switching-off Value
Fan relay switching-off temperature is defined in this menu.
First parameter is the operating temperature of the fan. Press SET button
to enter the settings.
Press SET button for 3 sec. in order to enter to the menu.
3 sec.
By UP/DOWN buttons, find fan relay settings (FAn) menu.
By UP/DOWN buttons, find FAn oFF menu as a second parameter.
