Ness Guardpost Installation & Programming
SPECIFICATIONS
SYSTEM
ONBOARD PIR 15m PIR motion sensor
ONBOARD SIREN 124dBM
DIALLER Quad band GSM
BATTERY 12 Volt 3.2Ah SLA provides internal power in low-current modes / provides backup power in
Mains mode
USER INTERFACE
DISPLAY 6 Character scrolling LED
VOICE FEEDBACK Onboard voice + language options
OPERATION Arm / Disarm / Panic / Programming by radio keys
Arm / Disarm by SMS messaging
EVENT LOG Last 5 events with voice announcement
SETUP
SYSTEM PROGRAMMING Local programming by radio keys
Self learning of radio devices by local programming
Off site programming by SMS messaging
RADIO DEVICES
DEVICES SUPPORTED Up to 24 Ness Radio Keys or Radio Devices including the onboard PIR
RADIO SECURITY Proprietary encryption and supervision
Radio jamming detection
Radio substitution detection
RADIO RX/TX Ness integrated receiver for radio device signals
Ness Radio Siren transmitter onboard
RADIO FREQUENCY 304Mhz / 868MHz depending on local requirements
INPUTS / OUTPUTS
EXTERNAL WIRE LOOM RED/BLACK. Strobe output: 12V strobe light, max. 2
RED/BLUE. Siren output: 8 Ohm horn speaker, max. 1
RED/WHITE. Internal siren output: 12V screamer, max. 1
YELLOW/GREEN. Tamper input: 3k3 end of line (resistor supplied)
RED/RED FLYING LEADS. External input for hardwired 17VAC supply or solar panel supply
EXTERNAL POWER 17VAC Plug Pack supplied for periodic battery charging or for full-time power
External input for hardwired 17VAC supply, (see External Wire Loom)
External input for solar panel power supply, (see External Wire Loom)
PHYSICAL
DIMENSIONS, MAIN UNIT 515(h) x 112(w) x 80mm(d)
COMPLIANCE
APPROVALS C-TICK, CE
