The R16 control panel stores a comprehensive
event memory including Arming, Disarming, Low
Battery, Mains Fail and Alarms.
The memory is constantly upgraded and the last
20 events are always available for viewing.
This memory display can only be selected while
the panel is in the Disarmed state.
TO CLEAR THE MEMORY ICON
The MEMORY icon on the LCD display flashes
continuously when an alarm has occurred as a
reminder to view the alarm memory.
The MEMORY icon stops flashing after the
memory is viewed as shown above.
The MEMORY icon is automatically cleared
next time the panel is Armed and on entry to
program mode.
OPERATION - VIEW MEMORY
VIEWING MEMORY
The most recent event will be displayed.
The next most recent event will be displayed.
...and so on (up to the last 20 events).
Press...
Press...
Press...
Press...
The
to exit Memory mode.
MEMORY icon will turn on.
or...
Press...
[User Code]
