NESS R16 CONTROL PANEL - USER MANUAL
SPECIFICATIONS
RADIO ZONES
16
HARDWIRED ZONES
1 (operates in series with zone 16)
HARDWIRED TAMPER ZONES
1
RADIO COMPATIBILITY
Ness supervised & encrypted radio devices
DIALLER FORMAT
Contact ID Format
Audible Voice Format
ON BOARD KEYPAD
Backlit, programming & user functions
LCD DISPLAY
High contrast icon display
PLUG PACK
220-240V AC 50-60Hz, output 17V AC @300mA
QUIESCENT CURRENT DRAW
10 mA (in power save mode if mains is off)
BUILT-IN BACKUP BATTERY
12 volt 0.8 Amp/hour, sealed lead acid
DYNAMIC BATTERY TEST
Every Hour and on arming/disarming
FUSES
Siren Output, 2A Auto-reset
Strobe, 1.5A Auto-reset
Piez Output, 500mA Auto-reset
Built-in Piezo, 500mA Auto-reset
SIREN OUTPUT
1 x 8 Ohm horn speaker max.
ON BOARD PIEZO SIREN
110 dB
PIEZ (RESET) OUTPUT
12V DC 300mA max.
STROBE OUTPUT
12V DC, 1 strobe light max.
DIMENSIONS
210(w) x 145(h) x 40(d) mm
