NETGEAR AV Series Hardware Installation Guide

Switch hardware interfaces
This section describes the hardware interfaces that are common to the M4250 series
switch models.
1GBASE-T RJ-45 and 2.5GBASE-T RJ-45 copper ports
All 1GBASE-T RJ-45 and 2.5GBASE-T RJ-45 copper ports support autosensing. When
you insert a cable into an RJ-45 port, the switch automatically detects the maximum
speed (10 Mbps, 100 Mbps, 1 Gbps, or 2.5 Gbps) of the attached device. For devices
that support 10 Mbps or 100 Mbps, the switch automatically detects the duplex mode
(half-duplex or full-duplex). All ports support a Category 5 (Cat 5) unshielded twisted-pair
(UTP) cable or higher-rated Ethernet cable terminated with an 8-pin RJ-45 connector.
For more information about Ethernet cables, see Cables and speed on page 26.
Note: Use a Category 5e (Cat 5e) or higher-rated cable for a copper port at 1 Gbps.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink
technology. This technology allows attaching devices to the RJ-45 ports with either
straight-through or crossover cables.
When you insert a cable into the switch’s RJ-45 port, the switch automatically performs
the following actions:
•
Senses whether the cable is a straight-through or crossover cable.
•
Determines whether the link to the attached device requires a normal connection
(such as when you are connecting the port to a computer) or an uplink connection
(such as when you are connecting the port to a router, switch, or hub).
•
Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections
while eliminating concern about whether to use crossover or straight-through cables
when you attach devices.
PoE port capacities and budgets
The Power over Ethernet (PoE) models support eight PoE+ or PoE++ ports with the port
capacities and budgets that are described in the following table.
Hardware Installation Guide23Hardware Overview
AV Line of Fully Managed Switches M4250 Series

NETGEAR AV Series Specifications

General

Model	AV Series
Switching Capacity	Varies by model
Quality of Service	Yes
Jumbo Frame Support	Yes
Energy Efficient Ethernet	Yes
Ports	5, 8, 16
Layer	Layer 2
Mounting	Desktop
Speed	Gigabit Ethernet
Power Budget	Varies by model
Fanless Design	Yes
